Transparent LED Displays TF series
Product Description: Limitless sizes options Extended lifetime Easy to upgrade Designed with the highest resolution Modular Structure, support customization
Contact Us
Home
ProductTransparent LED Displays
Transparent LED Displays TF series
Black
Extraordinary deep blacks
Brilliant
Capture every brilliance
Cool
Stay cool, enjoy more
Strong
Against external impact
Flip Chip Technology
High reliability
Energy-saving Technology
Less consumption
Product Features
As thin as 1.8mm
The thickness of the screen is less than 2mm,and it is seamlessly attached on a curved surface to show an integral whole on the transparent glass.
Holographic 3D suspension images
Display effect of 3D holographic and spatial suspension images.
Flexible
Standard module can be bent and skillful applications. It is the best partner of curved glass and irregular screens.
Applications of LED Film Displays
Glass Curtain Walls & Storefronts — maintain transparency with digital signage

Shopping Malls & Brand Flagship Stores — high‑impact promotional zones

Showrooms & Automotive Displays — premium visual engagement

Museums & Galleries — subtle digital layer on transparent surfaces

Corporate Lobbies & Conference Areas — luxury info displays

Airports & Transportation Hubs — engaging wayfinding & ads
Specifications
LV-TF25
Pixel Pitch
2.5/2.5mm
Pixel Density(dot/m2)
160,000pixels/sqm
Transparency Rate
70%
Profile Dimension (mm) (w*h)
125x1025/125x1200
Resolution (dot) (w*h)
50x400/50x470
Brightness(cd/m)
>1200
Weight(Kg/set)
1.63
Scanning Mode
Static Driving (Single Pixel Single Control
Lifespan
>100,000.00 hours
Pixel Configuration
16bit
Power Consumption (w/m2)
Max: 800W/m2; Avg: 350W/m2
Input Voltage
AC100~240V 50/60Hz
Working Temperature
Temperature -20°C~50°C
Working Humidity
Humidity: 20% -85%(Without Condensation)
Protation Degree
IP20
Installation Environment
Indoor
Packing Way
Pearl Cotton+Wooden case/Airbox
LV-TF39
Pixel Pitch
3.91/3.91mm
Pixel Density(dot/m2)
65,536pixels/sqm
Transparency Rate
80%
Profile Dimension (mm) (w*h)
250x1025/250x1200/250x1500
Resolution (dot) (w*h)
64x256/64x300/64x376
Brightness(cd/m)
≥2000
Weight(Kg/set)
1.6
Scanning Mode
Static Driving (Single Pixel Single Control
Lifespan
>100,000.00 hours
Pixel Configuration
16bit
Power Consumption (w/m2)
Max:1000W/m2; Avg: 375W/m2
Input Voltage
AC100~240V 50/60Hz
Working Temperature
Temperature -20°C~50°C
Working Humidity
Humidity: 20% -85%(Without Condensation)
Protation Degree
IP20
Installation Environment
Indoor
Packing Way
Pearl Cotton+Wooden case/Airbox
LV-TF62
Pixel Pitch
6.25/6.25mm
Pixel Density(dot/m2)
25,600pixels/sqm
Transparency Rate
90%
Profile Dimension (mm) (w*h)
250x1200/250x1500
Resolution (dot) (w*h)
40x188/40x236
Brightness(cd/m)
≥5000
Weight(Kg/set)
1.6
Scanning Mode
Static Driving (Single Pixel Single Control
Lifespan
>100,000.00 hours
Pixel Configuration
16bit
Power Consumption (w/m2)
Max:1000W/m2; Avg: 375W/m2
Input Voltage
AC100~240V 50/60Hz
Working Temperature
Temperature -20°C~50°C
Working Humidity
Humidity: 20% -85%(Without Condensation)
Protation Degree
IP20
Installation Environment
Indoor
Packing Way
Pearl Cotton+Wooden case/Airbox
LV-TF10
Pixel Pitch
10/10mm
Pixel Density(dot/m2)
10,000pixels/sqm
Transparency Rate
85%
Profile Dimension (mm) (w*h)
260x1000/260x1200
Resolution (dot) (w*h)
26x100 /26x120
Brightness(cd/m)
≥4000
Weight(Kg/set)
1.2
Scanning Mode
Static Driving (Single Pixel Single Control
Lifespan
>100,000.00 hours
Pixel Configuration
16bit
Power Consumption (w/m2)
Max:1000W/m2; Avg: 375W/m2
Input Voltage
AC100~240V 50/60Hz
Working Temperature
Temperature -20°C~50°C
Working Humidity
Humidity: 20% -85%(Without Condensation)
Protation Degree
IP20
Installation Environment
Indoor
Packing Way
Pearl Cotton+Wooden case/Airbox
Download Full Specsheet
