LED Double-sided
Product Description: Double-sided have unique designs for both outdoor and indoor installations. You probably see them in stage setups for corporate events, music festivals, trade show booths, LED billboards for advertising, and other similar venues.
Contact Us
Home
ProductRetail LED Solutions
LED Double-sided
Black
Extraordinary deep blacks
Brilliant
Capture every brilliance
Cool
Stay cool, enjoy more
Strong
Against external impact
Flip Chip Technology
High reliability
Energy-saving Technology
Less consumption
Product Features
Features
Compact and modular structure
Fast assembly and dismantling
High refresh rate for filming and livestreaming
Durability for repeated transport
Advantages
Long Lifespan
Programmable
Environmentally Friendly
High-Quality Images
Applications
Airports
Subway stations
Hotels and bars
Hospitals
Banks
Advertisement displays
Shopping mall directories
Entertainment plaza & stadium
DJ booths
Specifications
LV-DS1.5- 2X1D Double-sided
Pixel Pitch
1.538mm
Pixel Density
422,500pixels/sqm
Application
Indoor
LED Configuration
GOB1212
Module Size
320*160mm
Module resolution
208*104dots
Shown Size
320*320mm Double-sided
Cabinet Size
340*340 mm
Display Resolution
416*208dots
Best Viewing distance
≥1.5m
Brightness
600-800nits
Brightness
5000cd
Refresh Rate
3840 Hz
Best Viewing Angle
X:140° / Y:120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front /Rear Maintaence
Power Consumption
<360W/m²
Life Span
100,000Hours
LV-DS1.8- 2X1D Double-sided
Pixel Pitch
1.86mm
Pixel Density
288,906pixels/sqm
Application
Indoor
LED Configuration
SMD1515
Module Size
320*160mm
Module resolution
172*86dots
Shown Size
320*320mm Double-sided
Cabinet Size
340*340 mm
Display Resolution
344*172dots
Best Viewing distance
≥1.8m
Brightness
600-800nits
Brightness
5000cd
Refresh Rate
3840 Hz
Best Viewing Angle
X:140° / Y:120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front /Rear Maintaence
Power Consumption
<360W/m²
Life Span
100,000Hours
LV-DS2- 2X1D Double-sided
Pixel Pitch
2mm
Pixel Density
250,000pixels/sqm
Application
Indoor
LED Configuration
SMD1515
Module Size
320*160mm
Module resolution
160*80dots
Shown Size
320*320mm Double-sided
Cabinet Size
340*340 mm
Display Resolution
320*160dots
Best Viewing distance
≥2m
Brightness
600-800nits
Brightness
5000cd
Refresh Rate
3840 Hz
Best Viewing Angle
X:140° / Y:120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front /Rear Maintaence
Power Consumption
<360W/m²
Life Span
100,000Hours
LV-DS2.5- 2X1D Double-sided
Pixel Pitch
2.5mm
Pixel Density
160,000pixels/sqm
Application
Indoor
LED Configuration
SMD1515
Module Size
320*160mm
Module resolution
128*64 dots
Shown Size
320*320mm Double-sided
Cabinet Size
340*340 mm
Display Resolution
256*128dots
Best Viewing distance
≥2.5m
Brightness
600-800nits
Brightness
5000cd
Refresh Rate
3840 Hz
Best Viewing Angle
X:140° / Y:120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front /Rear Maintaence
Power Consumption
<360W/m²
Life Span
100,000Hours
Download Full Specsheet
