Transparent LED Displays TW series
Product Description: Delivers clear visuals while maintaining high transparency for open sightlines on glass surfaces. High refresh rate ensures smooth, flicker-free content performance. Ultra-slim and lightweight design minimizes load on glass and façades. Built for reliable, long-term operation in commercial environments.
Contact Us
Home
ProductTransparent LED Displays
Transparent LED Displays TW series
Black
Extraordinary deep blacks
Brilliant
Capture every brilliance
Cool
Stay cool, enjoy more
Strong
Against external impact
Flip Chip Technology
High reliability
Energy-saving Technology
Less consumption
Product Features
Light weight of 6kg/m2
With professional aesthetic design, the display screen is lightweight and beautiful and weighs only 6kg/m2
High brightness & high contrast
9,000:1 (high contrast),
5,000cd/m 2 (high brightness),
dazzling and eye-catching.
Transparent and excellent image quality
Equally spaced pixel layout for high-definition image quality; static scanning with combined diver board for table images;16bit gray scale with exquisite colors.
Modular Transparent Design
Designed for linear and hanging installations, transparent LED banners deliver dynamic content while maintaining open sightlines.
Specifications
LV-TW26S
Pixel Pitch
H:2. 6MM, V: 5. 2mm
Resolution
73728pixels/sqm
LED Configuration
SMD1515
Module Size
500x125x5mm
Module Resolution
192 x24dots
Panel Size
1000*500mm
Panel Resolution
384*96dots
Refresh Rate
>1920Hz
Panel Weight
5kg
Brightness
>3000nits
Best Viewing Distance
>4m
Best Viewing Angle
120°/120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front Maintenance (Back optional)
Power Consumption
Max: 300W; Avg: 120W
Life Span
100,000 Hours
LV-TW39S
Pixel Pitch
H:3.9MM, V:7.8mm
Resolution
32768pixels/sqm
LED Configuration
SMD1921
Module Size
500x125x5mm
Module Resolution
128x16dots
Panel Size
1000*500mm
Panel Resolution
256*64dots
Refresh Rate
>1920Hz
Panel Weight
5kg
Brightness
>3000nits
Best Viewing Distance
>4m
Best Viewing Angle
120°/120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front Maintenance (Back optional)
Power Consumption
Max: 300W; Avg: 120W
Life Span
100,000 Hours
LV-TW26H
Pixel Pitch
H:2. 6MM, V: 5. 2mm
Resolution
73728pixels/sqm
LED Configuration
SMD1515
Module Size
500x125x5mm
Module Resolution
192 x24 dots
Panel Size
1000*1000mm
Panel Resolution
384*192dots
Refresh Rate
>1920Hz
Panel Weight
10kg
Brightness
>3000nits
Best Viewing Distance
>4m
Best Viewing Angle
120°/120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front Maintenance (Back optional)
Power Consumption
Max: 600W; Avg: 240W
Life Span
100,000 Hours
LV-TW39H
Pixel Pitch
H:3.9MM, V:7.8mm
Resolution
32768pixels/sqm
LED Configuration
SMD1921
Module Size
500x125x5mm
Module Resolution
128 x 16 dots
Panel Size
1000*1000mm
Panel Resolution
256*128dots
Refresh Rate
>1920Hz
Panel Weight
10kg
Brightness
>3000nits
Best Viewing Distance
>4m
Best Viewing Angle
120°/120°
Working Voltage
AC200~240V (+/-10%)
Maintenance Way
Front Maintenance (Back optional)
Power Consumption
Max: 600W; Avg: 240W
Life Span
100,000 Hours
